HPL, 15 mm
GP500
Sturdy, high-quality swing door for the food industry
The GP500 HPL swing door combines high durability with an attractive design and is the ideal solution for high-traffic passageways. It consists of a 15 mm thick HPL door leaf (compact board) and is particularly impact-resistant and durable. Thanks to a wide range of decorative options, including custom printing, it blends harmoniously into restaurants, retail spaces and other high-end settings.
180° (2 × 90°) opening angle
Single-leaf and double-leaf
Access for persons
Minimum dimensions: 600/1250 x 1800 mm
Maximum dimensions: 1400/2800 x 2800 mm
Special sizes available on request.
Areas of application
Restaurants
Ideal for kitchens, service areas and ancillary spaces with high footfall and a sophisticated look.
Sales areas
Suitable for shop entrances and internal passages where design, stability and functionality are key.
Public institutions
Ideal for nurseries, schools, theatres and similar venues where a robust build and attractive design are equally important.
GP500 HPL swing door with flat profile and stainless steel kickplate, single-leaf
GP500 HPL swing door with flat profile, double-leaf
Advantages
Maintenance-free
Durable and long-lasting
Faster and easier through traffic
Food-safe
High degree of prefabrication
Temperature range from –30 °C to +60 °C
Customised manufacturing made to order
Colours
Wood finishes
Colour deviations are due to technical reasons.
Beech body
Serenissima
Delano Nussbaum
Akari
Canto
Silver spruce brown
Arezzo
Finca
Castello
Sereno
Silvretta
Cognac oak
Fortuna
Aristo
Custom printing and plain designs are available. Other decorations available on request.
Window shapes
flush-fitting and frameless
Our acrylic glass panels are 15 mm thick, frameless and flush-fitting.
We are happy to produce special shapes on request.
Options
Hinge technology
- Stainless steel hinge, optionally available with or without a 90° stop
- Stainless steel hinge, adjustable to the middle position
Lock
Stainless steel lock with a profile cylinder
- Lockable on both sides
- Fitted at the top, bottom or side of the door leaf
- Fitting flush with the lintel
Window shapes
Standard forms
- Round (400 mm)
- Rectangular (400 x 600 mm)
- Half-round (400 x 950 mm)
Special shapes available on request.
Seals
- Black or transparent
- Without finger protection with a round edge
- PVC finger protection from a height of 900 mm
- PVC finger protection at door height
Handle
- On both sides or one-sided
- 200 or 400 mm long
- In a black plastic mount
PE Stopper
- For opening the door from one side
- Fastening under the lintel
Impact absorber profile
- Stainless steel kickplate made from 1,5 mm stainless steel, 190 mm high, on both sides, from the bottom edge of the door leaf
Stainless steel lever handle sheet
- Rectangular (200 x 300 mm)
- Half-round (350 mm)
