Stainless steel/steel 1,5 mm, 40 mm
GP400
Hygienic stainless steel swing door for professional working environments
The GP400 stainless steel swing door is a durable and hygienic solution for professional working environments with high standards of cleanliness and durability. The door leaf, made from high-quality stainless steel with a CFC-free foam core, offers a smooth, easy-to-clean surface and impresses with its high functionality and premium appearance. Matching stainless steel door frames are available to create a harmonious overall look.
180° (2 × 90°) opening angle
Single-leaf and double-leaf
Access for persons
Minimum dimensions: 550/1100 x 1800 mm
Maximum dimensions: 1450/2900 x 2800 mm
Special sizes available on request.
Areas of application
Food processing & fresh food sections
For supermarkets, preparation areas and workspaces where hygiene is a priority.
Catering & Commercial Kitchens
Ideal for kitchens, canteens and washing-up areas with high footfall.
Healthcare
Suitable for hospitals, clinics and areas with high hygiene standards.
GP400 stainless steel swing door with U-frame, double-leaf
GP400 stainless steel swing door with U-frame, single-leaf
Advantages
Maintenance-free
Durable and long-lasting
Faster and easier through traffic
Food-safe
High degree of prefabrication
Temperature range from –30 °C to +60 °C
Customised manufacturing made to order
Colours
Stainless steel
Circular-brushed stainless steel
Brushed stainless steel
Steel
Colour deviations from the RAL colour chart are due to technical reasons.
RAL 9010
Pure white
RAL 9006
White Aluminium
RAL 9002
Grey-white
RAL 7016
Anthracite grey
RAL 5010
Gentian blue
RAL 3000
Fire red
Window shapes
with stainless steel window frames
Our laminated safety glass units are 8 mm thick.
We are happy to produce special shapes on request.
Options
Hinge technology
- Stainless steel hinge, optionally available with or without a 90° stop
- Stainless steel hinge, adjustable to the middle position
Lock
Stainless steel lock with a profile cylinder
- Lockable on both sides
- Fitted at the top of the door leaf
- Fitting flush with the lintel
Window shapes
Standard forms
- Round (400 mm)
- Rectangular (400 x 600 mm)
Special shapes available on request.
Stainless steel window frames.
Seals
- Black
- At door height
Handle
- On both sides or one-sided
- 200 or 400 mm long
- In a black plastic mount
PE Stopper
- For opening the door from one side
- Fastening under the lintel
Impact absorber profile
- PE bumper made from 15 or 10 mm thick PE, 200 – 1200 mm high, on both sides, variable fitting height, standard colours
- Teardrop bumper made from 5 mm PE, 300 – 1200 mm high, on both sides, adjustable mounting height, black (other colours available on request)
- Stainless steel kickplate made from 1,5 mm stainless steel, 200 mm high, on both sides, from the bottom edge of the door leaf
Stainless steel lever handle sheet
- Rectangular (200 x 300 mm)
- Half-round (350 mm)
